Superheat and subcooling calculator
Two pressures, two temperatures, one verdict. Which number decides the charge depends entirely on the metering device — the control at the top switches between them.
Pre-filled with a typical R-410A system at 95 °F outdoor, 63 °F indoor wet bulb.
psig
°F
psig
°F
119.3°F
Subcooling — overcharged — subcooling above the target band
Safety — Refrigerant work is certified work
Opening a sealed system in the United States requires EPA Section 608 certification, and R-454B is a mildly flammable A2L refrigerant with its own handling, leak-detection and ventilation requirements. Gauges on a system you are not certified to service is not a grey area.
What the two numbers measure
Superheat is how many degrees above its boiling point the vapour leaving the evaporator has been heated. It tells you whether the evaporator is being fed enough refrigerant. Subcooling is how many degrees below its condensing point the liquid leaving the condenser has been cooled. It tells you how much liquid is stacked in the condenser — which is to say, how much refrigerant is in the system.
Both are the same subtraction: measure a pressure, convert it to a saturation temperature, and compare that to the actual line temperature at the same point.
Which one to charge by
| Metering device | Charge by | Typical target | Why |
|---|---|---|---|
| Fixed orifice / piston | Superheat | Calculated, 5–25 °F | The orifice does not adjust; superheat moves with charge |
| TXV | Subcooling | 8–12 °F | The valve holds superheat constant, so it cannot report charge |
| EEV | Subcooling | Per manufacturer | Same reason, electronically |
Charging a TXV system by superheat is the classic mistake
A thermostatic expansion valve exists to hold superheat at its setpoint. It will do that across a wide range of charges, right up until it starves. So a superheat reading on a TXV system tells you the valve is working, not that the charge is correct. Read subcooling instead, and read it against the number on the equipment's own charging plate.
Target superheat for a fixed orifice
On a fixed-orifice system the target moves with conditions. The standard field approximation is (3 × indoor wet bulb − 80 − outdoor dry bulb) ÷ 2. At 63 °F indoor wet bulb and 95 °F outdoor that is 7 °F; on a mild 75 °F day with the same indoor conditions it rises to 17 °F. Charging to a fixed "10 degrees" on a cool day overcharges the system every time.
Before you touch the gauges
Most charge complaints are not charge problems. Confirm airflow first: a dirty filter, a collapsed flex duct or a blocked return will drag suction pressure down and look exactly like an undercharge. Take the static pressure reading with the static pressure calculator before you connect a manifold, and check the coil and condenser are clean.
Section 608 of the Clean Air Act (40 CFR part 82, subpart F) bans intentional venting of ODS refrigerants and their substitutes, including HFCs, during service, repair or disposal. R-454B systems bring the additional requirements EPA's AIM Act technology-transition rules put on A2L equipment — epa's technology transitions programme under the aim act sets sector and subsector limits on hfc use in refrigeration, air conditioning and heat pumps. The R-454B guide covers what changes in the van and on the roof.
Sources: US EPA, Stationary Refrigeration and Air Conditioning (read 2026-09-04) · US EPA, Technology Transitions (page last updated 2025-12-03) (read 2026-09-04)
